The Slim Tray System.
Our own mounting concept for ACM cladding, designed so panels can be identified, sequenced and installed with precision.
Our system
Slim Tray System.
Our own mounting concept, shown in 3D. Rotate the model, change the ACM finish and open the exploded view to see how the face sheet, trays, strips and profiles come together.
ACM finish
Exploded view
Illustrative 3D model. Finishes shown for visualization; final panel finish is selected per project.
How the system is built
The model above shows the main parts of the Slim Tray System: the ACM face sheet, formed trays, filler strips and the support profiles at the start, front and back of the assembly. Open the exploded view to see each layer.
Why it matters
- Every part has a defined role and position, which makes panels easier to identify and sequence
- Information from the 3D model carries through to fabrication and the installation map
- Fewer improvised decisions on site
Each project is reviewed and detailed for its own conditions. Performance and suitability are confirmed per project with the design team.
